Gabion retaining wall design / gabion basket for facaed walls
The stone box system is quick and easy to install, we supply all the necessary fixings required to create the gabion effect, unlike traditional gabion baskets, the unique design of the stone box system will ensure that the gabion face will not misshape or deform over time.
By using a mesh and stone facing, your retaining wall will have a more natural appearance than a traditional precast concrete wall and will fit better into its surroundings.
| Welded Gabion specifications |
| Wire diameter:3.0-6.0mm |
| Size M | Mesh size MM | DiaphragmsNo. | CBM |
| 1.0*1.0*0.5 | 50*50 75*75 50*100 100*100 | 0 | 0.5 |
| 1.0*1.0*1.0 | 0 | 1.0 |
| 1.5*1.0*0.5 | 0 | 0.75 |
| 1.5*1.0*1.0 | 0 | 1.5 |
| 2.0*1.0*0.5 | 1 | 1.0 |
| 2.0*1.0*1.0 | 1 | 2.0 |
| 3.0*1.0*0.5 | 2 | 1.5 |
| 3.0*1.0*1.0 | 2 | 3.0 |
| 4.0*1.0*0.5 | 3 | 2.0 |
| 4.0*1.0*1.0 | 3 | 4.0 |
| The specifications can be customized. |
Advantages of Gabions:
Cost-Effective
Can product any size
Exceptional Durability
Quick and Easy to Install
Unique Design
Applications:
you’ll find them used extensively where a neat appearance and clean outline are important, such as public areas, housing developments, landscaping and gardens.
control and guide the direction of river,
spillway and diversion channel
rock fall protection,
prevent soil and water from flowing
beach protecting project
protection of the bridge
solid structures defense project
retaining wall
Packing details
Packing: In pallet or in bundle, put in wooden case or cartons,as buyer's requirement.
When requesting a quote, please specify:
size of units (LxWxH)
type of mesh size (50*50,100*100mm)
type of coating (galvanized wire, galfan wire)
Wire diameter(4mm,5mm)
